Locations for Engine Model Information:
- Stamped into the top or side of the flywheel blower housing.
- Stamped into the heaterbox of a snow engine
- Stamped into the crankcase above the oil filler
cap.
- Stamped into a tag and retained by a crankcase bolt
- Numbers may be obscured by paint or rust. A brass brush or pencil rubbing may help.
Briggs & Stratton |
|
HP RATING |
MODEL NUMBERS |
2.0 |
60100 |
3.0 |
62000,80000,82000, 83000, |
3.5 |
90000 thru 85000,100000, |
3.75 |
96000, 98000 |
4.0 |
85000, 96000,110000 thru |
5.0 |
98000,104000,124000,126000,130000 thru 132000,133000 |
5.5 |
115000,129000 |
6.0 |
133700,135700,146000 |
7.0 |
170000,171000,176000 |
8.0 |
190000 thru 195OOO |
8.5 |
196700 |
9.0 |
123000,161000,165000, |
10.0 |
220000 thru 222000,243000 |
11.0 |
251000 thru 255000 |
11.5 |
259700 |
12.0 |
280000,281000,282000 |
12.5 |
286000,290000 |
13.0 |
302000, 28M707 |
14.0 |
260000,261000,287700, |
15.0 |
28N707, 28Q777 |
16.0 |
303000,326000,401400,404400,404700 |
18.0 |
350000,350700, 421400, |
20.0 |
351000 |
Your patronage of M&D Mower links helps support this site.
Kohler |
HP RATING |
MODEL NUMBERS |
4.9 |
K90, K91 |
5.0 |
K121.C5 |
6.0 |
K141, CH6 |
7.0 |
K160. K161 |
8.0 |
K181, M8 |
10.0 |
K241,M10 |
11.0 |
CV11 |
12.0 |
K301.M12 |
12.5 |
CV 12.5.CH12.5 |
14.0 |
K321,M14,CV14,CH14 |
16.0 |
K341.M16, MV16.CV16 |
17.0 |
KT17 |
18.0 |
K361, M18, MV18, CV18, CH18 |
19.0 |
KT19 |
20.0 |
K532, M20, MV20, CV20, CH20 |
21.0 |
KT21 |
22.0 |
CV22, CH22 |
23.0 |
K582 |
24.0 |
K660 |
Tecumseh |
HP RATING |
MODEL NUMBERS |
1.75 |
SLV,VA,V17 |
2 |
AH520, H20, V20 |
2.25 |
H22,LAV22, LCV22,LV22, V22 |
2.5 |
H25, LAV25, LCV25. LV25, V25 |
2.75 |
AV520, V25 |
3 |
AH600, H30, LAV30, LCV30,TVS75 |
3.25 CI |
AV600, TVS60, TVS600 |
3.5 |
H35, LAV35, LCV35, LV35, V35, |
4 |
H40, HH40, HS40, LAV40, V40,TVS105, TVXL840 |
4.5 |
H45, V45 |
5 |
H50, HH50, HS50, LAV50, V50,TVS120.TVM125 |
5.5 |
H55, V55 |
6 |
H60, HH60, V60, VH60, TVM140 |
7 |
H70, HH70. HM70, V70, VA70,VM70, TVM170 |
7.75 CI |
TVS75 |
8 |
H80. HH80. HM80, V80, VH80,TVM195 |
9 CI |
TVS90 |
9.5 C.I. |
TVS90 |
10 |
HH100, HM100, VH100, VM100, |
10.5 C.I. |
ECV105, TVS105, TVXL105 |
11 CI |
EVC120, TNT120 |
12 |
HH120,OH120,TVM125 |
13.5CI |
TVM140 |
14 |
HH140.0H140 |
15 |
HH150 |
16 |
HH160, OH160 |
17 16 CI |
TVM170 |
18 |
OH180 |
19.41CI |
TVM195 |
22.00 C.I. |
TVM2200 |
Briggs & Stratton
Model Number Guide
Example- 130902
1 OR 2 DIGITS INDICATE PISTON DISPLACEMENT |
INDICATES BASIC DESIGN SERIES |
INDICATES -CRANKSHAFT POSITION -CARBURETOR
TYPE -GOVERNOR TYPE |
INDICATES -TYPE OF BEARING -REDUCTION
GEARS AND AUXILIARY DRIVES |
INDICATES -TYPE OF STARTER |
6 |
0 |
0--Horizontal shaft diaphragm
carburetor (SG) pneumatic governor |
0--Plain bearing, non-flange
mount |
0--Without starter |
8 |
1 |
1--Horizontal shaft diaphragm
carburetor (VJ) pneumatic governor |
1--Plain bearing, flange |
1--Rope starter |
9 |
2 |
2--Horizontal shaft diaphragm
carburetor (PJ) pneumatic or mechanical governor |
2--Sleeve bearing flange
mounting splash lube |
2--Rewind starter |
10 |
3 |
3--Horizontal shaft float
feed carburetor pneumatic governor |
3--Ball bearing flange mount
splash lube |
3--Electric starter only |
11 |
4 |
4--Horizontal shaft float
feed carburetor mechanical governor |
4--Ball bearing, flange
mounting pressure lubrication |
120 volt gear drive |
12 |
5 |
5--Vertical shaft diaphragm
carburetor (VJ) pneumatic governor |
5--Plain bearing gear (6
to 1)CCW rotation |
4--Electric starter only |
13 |
6 |
6--Open |
6--Plain bearing gear reduction |
12 volt belt drive |
16 |
7 |
7--Vertical shaft float
feed carburetor mechanical governor |
7--Plain bearing mower deck
mounting pressure lubrication |
5--Electric starter only |
17 |
8 |
8--Vertical shaft float
feed carburetor module fuel tank mechanical governor |
8--Plain bearing (PTO) perpendicular
to crankshaft |
12 volt gear drive |
19 |
9 |
9--Vertical shaft model
13 Pulsa Jet carburetor mechanical governor model 9, Prime-N-Pull carburetor
pneumatic governor |
9--Plain bearing auxiliary
drive parallel to crankshaft |
6--Alternator only |
22 |
A |
|
|
7--Electric starter 12 volt
gear drive with alternator |
23 |
B |
|
|
8--Vertical pull start or
side pull starter |
24 |
C |
|
|
(1) Digit 6 formerly
used for "Wind-up" Starter |
25 |
D |
|
|
|
76 |
E |
|
|
|
28 |
F |
|
|
|
29 |
G |
|
|
|
30 |
H |
|
|
|
32 |
l |
|
|
|
35 |
J |
|
|
|
40 |
K |
|
|
|
42 |
L |
|
|
|
|
M |
|
|
|
|
N |
|
|
|
|
0 |
|
|
|
|
P |
|
|
|
|
Q |
|
|
|
Thank you for your support which helps keep this site online.
Tecumseh Model Number
Guide
(EXAMPLE) 804 101 A
1st DIGIT |
2nd& 3rd DIGIT |
4th DIGIT |
5th & 6th DIGIT |
7th DIGIT |
CRANKSHAFT POSITION |
HORSEPOWER OR 2-CYCLE |
PRIMARY FEATURES |
ENGINE VARIATION NUMBER |
REVISION LETTER |
8 - Vertical |
00= 2 Cycle |
1 = Rotary Mower |
00 thru 99 |
|
9 - Horizontal |
02= 3 HP |
2 = Industrial |
00 thru 99 |
|
|
03= 3.5 HP |
3 = Snow King |
00 thru 99 |
|
|
04= 4 HP |
4 = Minibike |
00 thru 99 |
|
|
05= 5 HP |
5 = Tractor |
00 thru 99 |
|
|
06= 6 HP |
6 = Tiller |
00 thru 99 |
|
|
07= 7 HP |
7 = Rider |
00 thru 99 |
|
|
08= 8 HP |
|
|
|
|
10=10 HP |
|
|
|
|
12=12 HP |
|
|
|
|
14=14 HP |
|
|
|
|
16=16 HP |
|
|
|
|
18=18 HP |
|
|
|
SEARS:
The following is a list of model number
prefixes which identify the various manufacturers of Sears equipment:
113 - Shredder & Bagger |
502 - Murray |
131 - AYP |
536 - Noma |
143 - Tecumseh |
636 - Robin Trimmers |
234 - Weedeater |
663 - Air Cap |
247 - MTD |
809 - Noma |
358 - Poulan |
917 - AYP |
EXAMPLE: Model #917- 253591 The prefix
(917) indicated that AYP manufactured this unit.
